UHD LED Panels for Home

Bezel‑free UHD LED video walls for cinematic home theaters and outdoor living spaces. Indoor pixels from 0.78–1.25 mm; Outdoor MiniLED from 1.56–1.95 mm. Clean, professional installation and serviceable design.

Indoor Home Theater (UHD)

Ultra‑fine pixel pitches for close‑range viewing.

  • Pixel pitch options: 0.78125, 0.9375, 1.25 mm
  • LED chips: Mini Chip LED 3×6ML
  • Cabinet: 600 × 337.5 mm (≈ 23.62 × 13.29 in)
  • Weight: 8 lb per cabinet (≈ 3.63 kg)
  • Brightness: 200–2000 nit, adjustable
  • Contrast ratio: 30000:1
  • Refresh rate: 3840–7680 Hz
  • Gray scale: 13–22 bit
  • Certificates: UL / ETL / CE / ROHS

Common sizes & power

DiagonalCabinetsMax PowerAvg Power
108"16800 W250 W
135"251250 W400 W
162"361800 W600 W
216"643200 W1000 W

Outdoor Home Spaces (IP67 MiniLED)

Rugged, weather‑ready design for patios, decks, and pools.

  • Pixel pitch options: 1.5625, 1.953 mm
  • LED type: Mini Chip LED
  • Cabinet: 500 × 500 mm (≈ 19.69 × 19.69 in)
  • Waterproof rating: IP67
  • Brightness: 3500–4500 nit, adjustable
  • Contrast ratio: 20000:1
  • Refresh rate: 3840–7680 Hz
  • Gray scale: 12–16 bit
  • Certificates: UL / ETL / CE / ROHS

Common sizes & power

DiagonalCabinetsMax PowerAvg Power
115"15 pcs2500 W850 W
159"28 pcs4800 W1600 W

Features that make the difference at home

  • DCI‑P3 wide color gamut for rich, cinematic color.
  • High refresh rate (3840–7680 Hz) for ultra‑smooth sports and gaming.
  • High consistency module‑to‑module for uniform brightness and color.
  • Front maintenance and ultra‑simple installation to keep service easy.
  • Low power consumption with about 30% energy savings versus typical panels.
  • Eye protection design and anti‑glare surface for comfortable viewing.
  • Adjustable brightness from 200–2000+ nit to match ambient light.

Get a Quote Expert sizing help

Open UHD LED E‑Catalog (PDF)

Why a modular LED panel TV beats a traditional TV

Real‑world installation advantages and everyday performance.

  • Easy around tight corners, stairs, and elevators — cabinets are compact (600 × 337.5 mm) and lightweight (~8 lb each), so we move them in pieces and assemble on the wall. No wrestling a giant fragile glass TV through doorways.
  • Built to the room — seamless, bezel‑free panels let us size the display to your wall and viewing distance, not whatever TV sizes are in stock.
  • Cleaner install and service — front maintenance modules mean no rear access; wiring is tidy and serviceable.
  • Brighter, anti‑glare, adjustable — comfortable viewing in mixed lighting where traditional TVs struggle.
  • Scalable and upgradable — expand later by adding cabinets instead of replacing the whole TV.
Delivery in 5 days Tech support within 48 hours Get a Quote

Next steps

Tell us about your room, viewing distance, and goals — we’ll size and design the perfect system.

Contact Us
